SeRies ıı
Series II Examples
ABOUT THE SERIES II GUITAR
Our top of the line, the pinnacle of our craft, the Series II is where the standard list of specifications reads like a custom build.
Everything cool we make is already included on these guitars: stereo electronics, side LEDs, inlaid logo with mother of pearl and abalone,
gold plated hardware, and continuous wood backplates. But rarely do we make one of these fine instruments strictly to the spec sheet.
Most people add their own touches to make the guitar unique in the world.
At the heart of the Series II are the pickups and electronics. What looks like three pickups is actually two single coil pickups with a
centrally located “dummy” humcanceller. Gorgeous tone pours forth from this arrangement, and electronic hum balance controls accessible through
one of the back plates means no hum, anywhere. We’ve also taken measures against the modern bane of high frequency noise with an internal noise
canceling network. The result is the absolute quietest electronics available. Coupled with our low-pass filters with continuously variable Q
controls, the range of sounds available from a Series II is mind-expanding.
The soul of the Series II is the wood. Our standard neck recipe of Maple with Purpleheart gives an even response to both lows and highs.
Each type of wood plays a role in shaping the tone, and we'll help you decide where to cast each one when you order a custom Series II guitar.
SERIES II SPECIFICATIONS
| FEATURE | 6‑STRING |
|---|---|
| Scale length | 24.75 in, 25.50 in, or 28.00 in baritone |
| Neck woods | 7-piece Maple and Purpleheart |
| Fingerboard | Ebony |
| Nut width | 1.65 in |
| 24th fret width | 2.25 in |
| Headstock | Crown |
| Truss rods | dual, body adjust |
| Top wood | Any standard or premium wood |
| Body wood | Mahogany |
| Sandwich | Double thick top, body wood |
| Body depth | 1.65 in |
| Finish | Polyester gloss with satin neck |
| Pickups | Alembic SC1 with HX |
| Controls | vvolume, filter, CVQ for each pickup; pickup selector switch, mono/stereo switch, master volume, LED on/off (optional) |
| Backplates | Continuous Wood |
| Bridge | Solid polished brass |
| Tailpiece | Solid brass, bird shape |
| Nut | Solid brass, height adjustable |
| Hardware finish | 24 karat gold-plated |
| Machine heads | Gold Alembic‑Gotoh |
| Average weight | about 9.5 pounds |
| Overall dimensions | Varies with the scale and body shape |
| Origin | 100% Made in Rohnert Park, CA USA |
